Motorino XPh - Sexy in Black with Green Metallic Flake
Born to Run
The MOTORINO XPh looks fast, even when standing still, and has the handling to match its sporting appearance. The extra-wide 120/70-12 low-profile front tire mounted on a lightweight cast-alloy wheel, low center of gravity, and long wheelbase provide great maneuverability and stability at speed. Its extended body provides ample legroom for the tallest of riders yet is still comfortable for almost anyone because of the low overall height. The floor-mounted battery pack is user-removable so it can be charged off-bike or quickly swapped.The large, locking under-seat storage area can be used for cargo or a secondary battery pack to extend your range. The XPh features a digital dash plus all standard XP-Series features including our high performance CCT Drive System, ABS-equipped hydraulic disc brakes front and rear, hydraulic telescopic front suspension, adjustable-preload rear shock absorbers, and alarm system.
Parts and Accessories
User's Manual
Unique Electric Drive Design
As seen on all MOTORINO™ XP models, this scooter is fitted with our unique CCT drive system. This drive system provides three electronic gears allowing selection of high torque, high speed or high range depending, on the riders preference and road conditions, while maintaining a high motor efficiency. Rated at 500W continuous power, our CCT system is capable of providing peak torque comparable to that seen in 50cc gas scooters with zero emissions and all the advantages of a Motor Assisted Cycle (MAC) classification (no licence, no insurance, free parking) Read more
Hydraulic Brakes with Anti-Lock Braking System (ABS)
The dual hydraulic disk brakes are equipped with an Anti-Lock Braking System (ABS) which ensures safe and effective braking. ABS is a very important feature for scooters as it greatly reduces the possibility of brake lock up and therefore provides the rider a better chance of steering out of trouble. Read more
Regenerative Braking System
The dual hydraulic disk brakes are equipped with an Anti-Lock Braking System (ABS) which ensures safe and effective braking. ABS is a very important feature for scooters as it greatly reduces the possibility of brake lock up and therefore provides the rider a better chance of steering out of trouble.
Specifications:
Drive System
Motor: MOTORINO CCT 48V high-torque three-phase AC permanent-magnet brushless.
Motor Controller: MOTORINO CCT microprocessor-controlled with regenerative braking.
Max torque: 66 Nm
Power System
Battery Pack
Standard Equipment: 48V 20A-h sealed lead-acid (SLA) main.
Optional: 48V 26A-h Lithium Ion (LiFePO4) main.
Optional: 48V 12A-h secondary pack (SLA only).
Protection
40A resettable circuit breaker, low-voltage cut-out (by controller), LiFePO4-only: internal over and under voltage cut-out.
Charging
Standard SLA: Outboard, 48V 3A Automatic Charger, 120VAC input ~7.5-hour charge time.
Optional SLA: Outboard, 48V 4A Automatic Charger, 120VAC input ~5.5-hour charge time.
Optional Lithium: Outboard, 48V 5A Automatic Charger, 120VAC input ~6-hour charge time.
12V Subsystem
Converter: DC/DC 48V>12V 10A (powers all lighting and accessory outlet).
12V Outlet: standard automotive lighter socket.
Running Gear
Brakes
Mechanical: front and rear hydraulic disk brakes with ABS (Anti-Lock Braking system).
Electric: regenerative, acting on rear wheel (via hub motor), triggered by front or rear brake actuation.
Suspension
Front: direct-acting twin internal spring/hydraulic shock.
Rear: trailing arm twin adjustable-preload coil-over spring/hydraulic shocks.
Tires & Wheels
Front:
Tire: 120/70-12” tubeless tubeless motorcycle grade DOT-spec.
Wheel: 3.5x12” cast alloy.
Tire: 3.5x10” tubeless motorcycle grade DOT-spec.
Wheel: 2.15x10” steel rim with integral motor, alloy side plates.
Body & Chassis
Available Colours
Black/Silver
Black/Green
Black/Yellow
Red/White
Frame
Motorcycle-grade high-tensile steel frame.
Shell
ABS composite, epoxy paint.
Pedals
Platform type, socketed removable cranks.
Seat
Padded, double place, 74cm (29”) above ground.
Instruments
Digital Speedometer/Odometer, Volt Gauge, Turn Signal/High Beam Indicators.
Safety equipment
Dual rear-view mirrors, horn, dual high/low beam headlights with running light, front and rear turn signals, tail light, brake light.
Security
Built-in vibration sensitive alarm system with two remote controls, steering Lock, helmet lock.
Performance
Range with standard SLA battery pack: up to 50km**
Range with optional LiFePO4 battery pack: up to 75km**
** based on flat terrain, no stops, no wind and 70kg (155lb) load.
Climbing ability:
Dimensions and Weights
Weight (without battery pack): 70kg (154lb).
Standard lead-acid (SLA) 48V 20A-h main battery pack: 27 kg (60lb).
Optional LiFePO4 (lithium) 48V 26A-h main battery pack: 14 kg (31lb).
Optional lead-acid (SLA) 48V 12A-h secondary battery pack: 17.7kg (39lb).
Wheelbase: 140cm (55”).
Overall length: 190cm (75”).
Maximum payload capacity, including rider(s): 135 kg (300 lb).
Included Accessories
12V electric tire inflator, with pressure gauge.
Riding rain cape.
Full-scooter poncho with hood and window for head light.
Scooter parking cover.
Tubeless tire repair kit.
Optional Accessories
Battery desulphator.
Helmet.
Windshield.
Wheel Lock.
Chain Lock.
Goggles.
Hand warmers.
